Online Catalog Table Of ContentsSummers Lens Bond optical cements are synthetic polymer adhesives manufactured under the strictest quality control. They are filtered to remove all particles larger than 1 micron in size, and filled under clean room conditions. These cements will meet and exceed military environmental specifications. LENS BOND Optical Cements are easy to use. Summers Optical cements are available "Off the shelf" and can be shipped within 24 hours (or sooner) of receipt of your order. Try our new Shopping Cart - Browse our online catalog with complete descriptions of all our products. Click on the shopping cart image to add an item to your cart. You can also use the Product Category lists to locate items to add to your shopping cart..
Optical Cements - Decementing Agents - Lens Coating Hardness Testers |
Optical Cements |
|
|---|---|
Two Component Optical Cements |
|
| Type C-59 | A two-component cement which meets Military Specification,
MIL-A-3920. NSN#804000-266082-8. |
| Type M-62 | A versatile two-component Cement used by companies producing large quantities of cemented doublets. Type M-62 is popular because of its accelerated oven-cure speed. This cement also meets Military Specification, MIL-A-3920. NSN#8040-00-148-7287. |
| Type F-65 | A two-component, room temperature, curing cement used in experimental and short-run projects, or where curing ovens are not available. Meets MIL-A-3920. |
| Type RD3-74 | A modification of Type F-65. This cement remains slightly elastic after curing. Meets Naval Drawing Number 639AS604. |
| Type DC-90 | A two-component, hybrid ultraviolet sensitive optical cement used in reducing strain in large elements. |
| Type DB-99 | DB-99 has been discontinued. |
UV Curing Optical Cements |
|
| Type UV-69 | A one-component, ultraviolet curing cement. Cure is achieved by using an ordinary sun lamp. NSN#8040-01-189-9644. |
| Type UV-74 | Lens Bond UV-74 has been discontinued. Please see J-91. |
| Type J-91 | A general purpose, one component, water white, 100% solids ultraviolet curing optical cement. This cement meets the requirements of MIL-A-3920. |
| Type HS-2 | An optically clear, single component, instant bonding (20 seconds) adhesive |
| Type P-92 | Type P-92 is no longer available. Please see other uv curing products on this page. |
| Type SK-9 | A single component, UV curing photopolymer which exhibits high adhesion to plastic. |
Structural Adhesives and Epoxies |
|
| Type EK-93 | A 100% solids epoxy system which is used as a structural adhesive or sealant. |
| Milbond Glass-to-Metal Adhesive System | A four component system that meets MIL-A-48611 NSN #8040-Ol-1390325 (Type I) NSN #8040-Ol-304-0784 (Type II) |
Decementing Agents |
|
|---|---|
| Lens
Bond Decementing Agent |
Easily and safely decements optical cements with little or no breakage. |
| Milsolve | An easy to use decementing agent for Milbond. |
| Milbond Seperation Film |
A protective water soluble film for those areas not being cemented. |
| Lens Bond Primer | A primer which assists in the bonding of difficult surfaces |
Lens Coating Hardness Testers |
|
|---|---|
| Testing Kit | A kit developed to test optical coatings on lenses that must meet military specifications. |
Cement Department Supplies |
|---|
| Mix Kit: For easier and more accurate mixing of 2 component cements |
| Individual Kit Components |
| Ultrasonic Baths and Cleaning Solutions |
| UltraViolet Lights |
| Liqui-Nox |
| Cotton Tipped Applicators |
| Optical Cleaning Cloth , EMS Lens Tissue, and Kimwipes |
|
Dust Off and Dust Blower |
| Pipettes |
| Dermal Protective Devices |
Optical Accessories |
|---|
| Stage Micrometers |
| Optical Resolution Charts |
| Calibration Standards Aids, Line Scales |
| Apertures |
Technical Data |
|---|
| Adhesion Properties/Solvent and Thermal Resistance/Laser Applications |
| Environmental Testing/Creep Test Results |
| Transmission Studies |
Problem Solving |
|---|
| Overview |
| Bonding Manual and Guide |
| Bond Failures - Causes and Remedies |
